Single-Span Arch Type Film Tunnel Greenhouse with Agriculture Hydroponic for Rose/Tulip/Tomato/Flower

GreenhouseFactory offers single-span arch type film tunnels for hydroponic agriculture of roses, tulips, tomatoes, and flowers. Visit our factory today!
Request a Quote

PRODUCTS DETAILS

  • Overview
  • Product Description
  • Main Products
  • Why Choose Us
  • Application
  • Company Profile
  • FAQ
Overview

Basic Info.

Model NO.
wxzw-5
Wind Load
0.52kn/M2
Snow Load
0.32knf/M2
Service Life
15years
Transport Package
Standard Packing
Specification
Customized
Trademark
zewo
Origin
Wuxi, Jiangsu, China
HS Code
843680
Production Capacity
1000000square Meters Per Year

Product Description

Product Description

Low cost greenhouse, film greenhouse, tunnel greenhouse

Its main feature is simple structure and flexible form.


(1) Simple structure Due to the characteristics of the covering material, the load-bearing structure, solid film system and installation requirements of the plastic greenhouse are relatively simple. Its bearing structure is made of hot-dip galvanized light steel or ordinary steel structure, and the bearing system without purlin system is generally adopted. The longitudinal rods are used as tie rods and connecting beams, which greatly simplifies the structure and reduces the amount of steel used. When the greenhouse adopts the covering material and the roof is not mechanically connected, the roof only bears the gravity load and positive wind pressure, and the wind pressure is transferred to the gutter and the column, which greatly optimizes the stress of the greenhouse structure. The solid film system of plastic greenhouse adopts two ways: fixed and detachable pressing. Fixed material can be anticorrosive wood strip, galvanized steel strip, aluminum alloy strip, etc. Detachable compacting solid film system is also known as "card slot ", card slot is composed of steel, aluminum alloy,PVC and other organic materials, according to the strength of the covering material, life, load bearing conditions, using different forms of card slot. With the development of industrial and greenhouse design technology, a product called "composite card slot" has gradually appeared. This kind of card slot organically combines structural parts with solid film parts, which can be used as load-bearing components and has the characteristics of solid film. At the same time, due to the solid film parts and component production as a whole, but also greatly improve the section characteristics of the component, improve the stiffness of the component and the ability to bear load, performance far component and slot separation structure, in the greenhouse specifications are more standardized, this will become a new technology characteristics and development direction.


(2) Flexible and diverse structure Due to the structural characteristics of plastic greenhouse, coupled with the development process of large plastic greenhouse, affected by regional, customer demand and other factors, all countries in the world are based on their own standards for the production and promotion of plastic greenhouse. Therefore, a large number of different forms, different specifications of plastic greenhouse products, such as different span, height and roof shape of the round vaulted greenhouse, double round arch pointed roof greenhouse, sawtooth greenhouse, small round arch multi-roof greenhouse, etc


Material Hot-dip galvanizing Span 6m,6.8m,8m,9.6m,12m
Frame Hot-dip galvanizing Length customizable
cover Film sun ,screen insect, repellent net Hihg 2.5-8m
Film PO,PE Insect control net 60mesh
Sunshade net 80% shading rate round silk ventilation Matching film


A fitting for connection:
Serial No. Item Picture Specification
1 pipe connector Single-Span Arch Type Film Tunnel Greenhouse with Agriculture Hydroponic for Rose/Tulip/Tomato/Flower   65 pcs
2 Pipe with holes Single-Span Arch Type Film Tunnel Greenhouse with Agriculture Hydroponic for Rose/Tulip/Tomato/Flower 22mm 57pcs
3 Spring Single-Span Arch Type Film Tunnel Greenhouse with Agriculture Hydroponic for Rose/Tulip/Tomato/Flower   195pcs
4 /film Single-Span Arch Type Film Tunnel Greenhouse with Agriculture Hydroponic for Rose/Tulip/Tomato/Flower 150 mirons thickness 1605m2
5 groove Single-Span Arch Type Film Tunnel Greenhouse with Agriculture Hydroponic for Rose/Tulip/Tomato/Flower 4 meters/pc 480m
6 groove spring Single-Span Arch Type Film Tunnel Greenhouse with Agriculture Hydroponic for Rose/Tulip/Tomato/Flower 2 meters/pc 480m
7 tension rope Single-Span Arch Type Film Tunnel Greenhouse with Agriculture Hydroponic for Rose/Tulip/Tomato/Flower   2 rolls
8 commecting slice Single-Span Arch Type Film Tunnel Greenhouse with Agriculture Hydroponic for Rose/Tulip/Tomato/Flower   120pc
9 bolt Single-Span Arch Type Film Tunnel Greenhouse with Agriculture Hydroponic for Rose/Tulip/Tomato/Flower   1 set
10 groove fasterner Single-Span Arch Type Film Tunnel Greenhouse with Agriculture Hydroponic for Rose/Tulip/Tomato/Flower 3 pcs/set 480 sets
11  fixing ring Single-Span Arch Type Film Tunnel Greenhouse with Agriculture Hydroponic for Rose/Tulip/Tomato/Flower   40 pcs
12 protecting  bush Single-Span Arch Type Film Tunnel Greenhouse with Agriculture Hydroponic for Rose/Tulip/Tomato/Flower   6 pcs
13 film squeezing clip Single-Span Arch Type Film Tunnel Greenhouse with Agriculture Hydroponic for Rose/Tulip/Tomato/Flower   220pcs
14 Greenhouse picture  Single-Span Arch Type Film Tunnel Greenhouse with Agriculture Hydroponic for Rose/Tulip/Tomato/Flower   4 pcs
15 Greenhouse picture Single-Span Arch Type Film Tunnel Greenhouse with Agriculture Hydroponic for Rose/Tulip/Tomato/Flower   1 set
16 Sunshade net Single-Span Arch Type Film Tunnel Greenhouse with Agriculture Hydroponic for Rose/Tulip/Tomato/Flower   24 pcs
17 Insect screen Single-Span Arch Type Film Tunnel Greenhouse with Agriculture Hydroponic for Rose/Tulip/Tomato/Flower   2 sets
Single-Span Arch Type Film Tunnel Greenhouse with Agriculture Hydroponic for Rose/Tulip/Tomato/Flower Single-Span Arch Type Film Tunnel Greenhouse with Agriculture Hydroponic for Rose/Tulip/Tomato/Flower
PO film

It has five layers: anti-fog, anti-drip, anti-age, anti-UV, anti-hail.

It can be used for 3-5 years according to local climate.

It has good light transmittance and also can help the crops from sunlight burning.


Insect control net

Insect-proof net is a kind of adding anti-aging, anti-UV and other chemical additives of polyethylene as the main raw material, by drawing made of mesh fabric, with high tensile strength, heat resistance, water resistance, corrosion resistance, aging resistance, non-toxic and tasteless, easy disposal of waste and other advantages. It can prevent common pests, such as flies and mosquitoes. Conventional use collection light, if the use of new materials and correct storage, life can reach 3-5 years or so.

Sunshade net:

Sunshade net, also known as sunshade net, is a new type of special protective covering material for agriculture, fishing, animal husbandry, windbreak and soil covering, which has been promoted for more than 10 years. Summer cover after a kind of light, rain, moisture, cooling effect. After winter and spring covering, there is a certain effect of heat preservation and humidification.

Main Products

Single-Span Arch Type Film Tunnel Greenhouse with Agriculture Hydroponic for Rose/Tulip/Tomato/Flower

Why Choose Us

Single-Span Arch Type Film Tunnel Greenhouse with Agriculture Hydroponic for Rose/Tulip/Tomato/Flower

Application

Single-Span Arch Type Film Tunnel Greenhouse with Agriculture Hydroponic for Rose/Tulip/Tomato/Flower

Company Profile

Single-Span Arch Type Film Tunnel Greenhouse with Agriculture Hydroponic for Rose/Tulip/Tomato/Flower

Wuxi Zewo Special Steel Co., Ltd. began to specialize in the production of greenhouse and greenhouse components in 2005.Our products are widely used in agricultural planting, scientific and technological research and development, leisure catering/entertainment, and other occasions and fields.Our products are reliable and long-lasting and backed by years of experience.

90% of our products are exported to all parts of the world.By leveraging our hard-won reputation for honesty, reliability and quality, Wuxi Zewo Special Steel Co., Ltd. aims to continue to be a pioneer in sales.

At the same time we are looking overseas for global partners. If your company is an end user, distributor or agent of greenhouse products, please contact us.
We look forward to working with you in the near future.

Single-Span Arch Type Film Tunnel Greenhouse with Agriculture Hydroponic for Rose/Tulip/Tomato/FlowerSingle-Span Arch Type Film Tunnel Greenhouse with Agriculture Hydroponic for Rose/Tulip/Tomato/Flower



FAQ



Q:
Are you Factory or Trading Company?

A:
We are factory, our main products include multi span greenhouse,film greenhouse,PC board greenhouse,glass greenhouse,single span greenhouse.


Q:
What is the Export Volume of your company?

A:
We have a 300000 tons export volume per year in the past, with the expansion of the markets,  the Export Volume is growing steady.


Q:
I need sample, could you support?

A:
We can supply you with the sample for free, but the delivery charges will be covered by our customers. For avoiding the misunderstanding, it is appreciated if you can provide the International Express Account for Freight Collect. Also you can have a visit to our factory,welcome to our factory .
